We built a library of common cross-sections details. They have been sorted by product group. They are available for download in PDF and DWG format.
What is a cross-section?
A cross-section shows how our products are attached to structures.
Detail Section
| Balustrade Handrail & Base Rail Ends |
Product Group: Balustrade
Attachment: N /A
Building Structure:
N / A
| Balustrade Attachment with Pin Anchors |
Product Group: Balustrade
Attachment: Pin Anchors
Building Structure:
N / A
| Cast Stone Balustrade Stair Attachment |
Product Group: Balustrade
Attachment: Pin Anchors
Building Structure:
N / A
| Cast Stone Banding Attachment at Masonry Veneer |
Product Group: Banding
Attachment: 1-Way Clip Anchor
Building Structure:
N / A
| Cast Stone Banding Attachment at Masonry Veneer |
Product Group: Banding
Attachment: Brick Tie
Building Structure:
N / A
| Typ. Cast Stone Solid Column |
Product Group: Column
Attachment: Pin Anchors
Building Structure:
N / A
| Typ. Cast Stone Hollow Column with Pipe |
Product Group: Column
Attachment: Pin & Wire Tie Anchors
Building Structure:
N / A
| Cast Stone Cornice Attachment at Stucco |
Product Group: Cornice
Attachment: 2-Way Clip Anchor and Blind Set Anchors
Building Structure:
N / A
| Cast Stone Cornice Attachment at Stucco |
Product Group: Cornice
Attachment: 2-Way Clip Anchor and Blind Set Anchors
Building Structure:
N / A
| Cast Stone Header Attachment at Masonry Veneer |
Product Group: Header
Attachment: Pin & Strap Anchors
Building Structure:
N / A
| Cast Stone Header Attachment at Masonry Veneer |
Product Group: Header
Attachment: Hidden Support Lintel and Pin & Wire Tie Anchor
Building Structure:
N / A
| Cast Stone Jamb Attachment at Stucco |
Product Group: Jamb
Attachment: Pin & Wire Tie Anchors
Building Structure:
N / A
| Cast Stone Jamb Attachment at Masonry Veneer |
Product Group: Jamb
Attachment: Pin & Strap Anchor
Building Structure:
N / A
| Cast Stone Panel & Watertable Attachment to Masonry Veneer |
Product Group: Panel
Attachment: 1 & 2-Way Clip Anchor and Pin & Wire the Anchor
Building Structure:
N / A
| Cast Stone Sill Attachment at Stucco |
Product Group: Sill
Attachment: Pin & Wire Tie and Blind Set Anchor
Building Structure:
N / A
| Cast Stone Sill Attachment at Masonry Veneer |
Product Group: Sill
Attachment: Pin & Strap Anchor
Building Structure:
N / A
| Cast Stone Sill Attachment at Masonry Veneer |
Product Group: Sill
Attachment: 2-Way Clip Anchor
Building Structure:
N / A
| Cast Stone Soffit Attachment at Structure |
Product Group: Soffit
Attachment: Biscuit Anchor
Building Structure:
N / A
| Cast Stone Soffit Attachment at Structure |
Product Group: Soffit
Attachment: Hook & Dowel Anchor
Building Structure:
N / A
| Typ. Cast Stone Tread & Riser Detail |
Product Group: Tread
Attachment: Pin Anchor
Building Structure:
N / A
| Cast Stone Wall Coping Attachment |
Product Group: Wall Cope
Attachment: Dowel Pin Anchor
Building Structure:
N / A
